Light Emitting Diode Led 5630 5730 , Green LED Chip 120 Degree Viewing Angle

Product Details:
Place of Origin: SHENZHEN
Brand Name: Yuhang
Certification: CE.SGS.ROHS
Model Number: YH5730G05
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days

Detailed Product Description



Type:smd led Chip Material:InGaN
Emitting Color:Green Luminous Intensity:Customers' Requirements
Luminous Flux(lm):30-40LM Power:0.5W
Viewing Angle(°):120 Degree Color Rendering Index:Null
Color Temperature:520-525nm Operating Temperature:-20 - 85
Chip Brand:Epistar Chip, Sanan Chip,Epileds Chip Current:150mA
Voltage:3.0-3.4V Warranty:2 Years
Lifespan:50000-100000H

Light Emitting Diode 5630 SMD 5730 Green LED chip 515nm 520nm 525nm 530nm

  • Features:

1. Very long operating life (up to100k hours).
2. Available in white, green, blue, red, yellow.
3. More energy efficient than incandescent and most halogen lamps.
4. Low voltage DC operated.
5. Cool beam, safe to the touch.
6. Instant light (less than 100 ns).
7. The product itself will remain within RoHS compliant Version.

  • Applications:

1. Reading lights (car, bus, aircraft).
2. Portable (flashlight, bicycle).
3. Mini_accent/Uplighters/Downlighters/Orientation.
4. Bollards/Security/Garden.
5. Cove/Undershelf/Task.
6. Automotive rear combination lamps.
7. Traffic signaling/Beacons/ Rail crossing and Wayside.
8. Indoor/Outdoor Commercial and Residential Architectural.
9. Edge lit signs (Exit, point of sale).
10. LCD Backlights/Light Guides.

Package Dimensions



            Light Emitting Diode Led 5630 5730 , Green LED Chip 120 Degree Viewing Angle

Recommended Soldering Patter

                     Light Emitting Diode Led 5630 5730 , Green LED Chip 120 Degree Viewing Angle





Product Type:YH5730G05
Absolute maximum ratings (Ta=25°C)
Parameter
Symbol
Value Unit
Forward current
If
150 mA
Reverse voltage Vr 5 V
Power dissipation Pd 450 MW
Operating temperature range Top -25~+80 °C
Storage temperature range Tstg -30~+85 °C

Peak pulsing current

(1/8 duty f=1KHz)

Ifp 200 mA
Electro-Optical characteristics (TA=25°C)
Parameter

Test

Condition



Symbol

Value Unit
Min Typ Max
Color Temperature If=150mA CCT -- -- -- K
Forward voltage If=150mA Vf 3.0 -- 3.6 V
luminous flux
If=150mA
φ 30 -- 40 Lm



Viewing angle at 50% IV

If=150mA 1/2 -- 120 -- Deg



Dominant wavelength

If=150mA
λd 520 -- 525 nm
Reverse current Vr=5V Ir -- 5 -- μA


Reel Dimensions:
0.80mm Height Top View White LED SMD Chip Promotion 3014 6000 -7500K


Carrier Tape Dimensions:
Loaded quantity 5000 PCS Per reel.

Light Emitting Diode Led 5630 5730 , Green LED Chip 120 Degree Viewing AngleLight Emitting Diode Led 5630 5730 , Green LED Chip 120 Degree Viewing Angle



Application field

Are widely used in the LED lamp, LED bulb light, LED panel light, LED ceiling lamp, LED street light, LED lamp, miner's lamp, stage light, flashlight, lighting, lamp lighting lamps and lanterns, as well as outdoor billboards, such as electronic display, traffic lights, signs, car tail lights, LED modules, LCD back light, LED lighting lighting, LED soft/hard light bar, etc., is the better choice to replace traditional lighting light source.
