PLCC4 Bi Color Smd Led Chip 3528 0.06 Watt White / Warm White Emitting Color

Product Details:
Place of Origin: SHENZHEN
Brand Name: Yuhang
Certification: CE.SGS.ROHS
Model Number: YH3527BICOLOR
Delivery Time: 5-7 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 8KK/Days

Detailed Product Description



Type:smd led Chip Material:InGaN
Emitting Color:White/warm White Luminous Intensity:Customers' Requirements
Luminous Flux(lm):W/WW:8-10LM Power:0.2W
Viewing Angle(°):120 Degree Color Rendering Index:70
Color Temperature:W:6000-6500K/WW:2800-3200K Operating Temperature:-20 - 85
Chip Brand:Epistar Chip, Sanan Chip,Epileds Chip Current:Single Color 20mA
Voltage:3.0-3.4V Warranty:2 Years
Lifespan:50000-100000H

PLCC4 3528 Diode 0.06W Bi-color Red+White, Yellow+White, Blue+White, Amber+White 3527 Bicolor SMD LED Chip



  • Features:

  • PLCC-4 package.

  • SMD LED type.

  • White package.

  • Optical indicator.

  • Colorless clear window.

  • Ideal for backlight and light pipe application.

  • Inter reflector.

  • Wide viewing angle.

  • Very long operating life.

  • Instant light (less than 100 ns).

  • Reading lights (car, bus, aircraft).

  • Mini_ accent/Up lighters/Down lighters/Orientation.

  • Bollards/Security/Garden.

  • Cove/Under shelf/Task.

  • Automotive rear combination lamps.

  • Indoor/Outdoor Commercial and Residential Architectural.

  • Edge_ lit signs (Exit, point of sale).

  • LCD Backlights/Light Guides.

  • Designed for high current operation.

  • Low thermal resistance.

  • Suitable for automatic placement equipment.

  • Suitable for vapor-phase reflow, Infrared reflow and wave solder processes.

  • The product itself will remain within RoHS compliant Version.

  •

    Applications:

  • Horticultural operations

  • Commercial vegetable and flower production

  • Supplemental greenhouse lighting

  • Hydroponics

  • Research experiment

  • Part No. Chip Material Lens Color Source Color
    YH3527bicolor AlGaInP Diffused BI-Color





Product Description

       PLCC4 Bi Color Smd Led Chip 3528 0.06 Watt White / Warm White Emitting Color

Product features:

1.High lumen: 8-10lm
2.Low Brightness Decay
3.Stable Performance & Great CCT Inity.
4Color Range:warm white, natural white, cool white,RGB.


Product quality:

1.good raw materials
2. Copper layer
3. Gold wire connection

4.Sanan chips
5. Lifespan is >50 000 hours easily



SURFACE MOUNT LED LAMPS
Product Type:YH3528BICOLOR
Absolute maximum ratings (Ta=25°C)
Parameter
Symbol
Value Unit
Forward current
If
40 mA
Reverse voltage Vr 5 V
Power dissipation Pd 0.2 W
Operating temperature range Top -25~+80 °C
Storage temperature range Tstg -30~+85 °C

Peak pulsing current

(1/8 duty f=1KHz)

Ifp 60 mA
Electro-Optical characteristics (TA=25°C)
Parameter

Test

Condition



Symbol

Value Unit
Min Typ Max
Color Temperature If=20mA CCT

6000

2800

---

6500

3200

K
Forward voltage If=20mA Vf 3 -- 3.4 V
luminous flux
If=20mA
φ 8 -- 10 LM



Viewing angle at 50% IV

If=20mA 1/2 -- 120 -- Deg



Color rendering index

If=20mA
CRI -- 70 -- Ra
Reverse current Vr=5V Ir -- 5 -- μA



PLCC4 Bi Color Smd Led Chip 3528 0.06 Watt White / Warm White Emitting Color





PLCC4 Bi Color Smd Led Chip 3528 0.06 Watt White / Warm White Emitting ColorPLCC4 Bi Color Smd Led Chip 3528 0.06 Watt White / Warm White Emitting Color







Application field

Are widely used in the LED lamp, LED bulb light, LED panel light, LED ceiling lamp, LED street light, LED lamp, miner's lamp, stage light, flashlight, lighting, lamp lighting lamps and lanterns, as well as outdoor billboards, such as electronic display, traffic lights, signs, car tail lights, LED modules, LCD back light, LED lighting lighting, LED soft/hard light bar, etc., is the better choice to replace traditional lighting light source.
